Sylcin 24V 200Ah Lifepo4 Battery
SC-24200
1.Strong Output: Designed for versatile drive applications
2.Smart BMS: 3-stage charging for extended lifespan
3.High Energy Density: Compact size, large capacity
4.Remote Monitoring: Optional WiFi/Bluetooth
5.Safe Design: Overcurrent, overtemperature & short-circuit protection
6.Customizable: OEM/ODM flexible solutions
2.Smart BMS: 3-stage charging for extended lifespan
3.High Energy Density: Compact size, large capacity
4.Remote Monitoring: Optional WiFi/Bluetooth
5.Safe Design: Overcurrent, overtemperature & short-circuit protection
6.Customizable: OEM/ODM flexible solutions
Quantity:
SylCin 24V 200Ah Lithium Battery Pack
The 24V 200Ah LiFePO4 battery delivers strong power and long-lasting energy for various industrial and off-grid applications. Designed with advanced lithium iron phosphate cells, this 24V 200Ah lithium battery provides high safety, long cycle life, and stable voltage output, making it a trusted energy solution for professionals.
24V 200Ah Lifepo4 Battery Details
24v Lithium Ion Battery Technical Specifications
| Items | Parameter | Parameter | Parameter |
| Rated Capacity | 100Ah | 200Ah | 250Ah |
| Minimum Capacity | ≥99Ah | ≥199Ah | ≥249Ah |
| Energy | 2560Wh | 5120Wh | 6400Wh |
| Nominal Voltage | 24V/25.6V | 24V/25.6V | 24V/25.6V |
| Open Voltage | 20~29.2V | 20~29.2V | 20~29.2V |
| Internal Impedance | ≤200mΩ | ≤200mΩ | ≤200mΩ |
| Charge voltage | 29.2V | 29.2V | 29.2V |
| Standard charge current | 50A | 100A | 125A |
| Max charge current | 50A | 100A | 125A |
| Standard discharge current | 100A | 200A | 250A |
| Max discharge current | 100A （Continuous） | 200A （Continuous） | 250A （Continuous） |
| Discharge cut-off voltage | 20V | 20V | 20V |
| Operating Temperature(Charging) | 0~+45℃ | 0~+45℃ | 0~+45℃ |
| Operating Temperature(Discharging) | -10~+60℃ | -10~+60℃ | -10~+60℃ |
| Storage Temperature | -20℃～+65℃ | -20℃～+65℃ | -20℃～+65℃ |
| Communication | RS485/CAN/RS232 | RS485/CAN/RS232 | RS485/CAN/RS232 |
| Size | 502*187*243mm | 550*322*240mm | 760*249*245mm |
| Net Weight | About 22kg | About 45kg | About 55kg |
| Model | SC-24100 | SC-24200 | SC-24250 |
SylCin 24V 200Ah Lithium Battery Pack Application Areas
The SylCin 24V 200Ah lifepo4 battery pack is suitable for a wide range of industrial and commercial applications, from logistics to construction, cleaning, and outdoor energy supply. It supports both continuous heavy-duty operations and long-duration power demands.
📦 Industrial & Logistics
- Electric forklifts, AGV automated transport vehicles, and warehouse handling equipment for improved operational efficiency.
🏌️ Recreational and Sightseeing Vehicles
- Electric sightseeing vehicles and golf carts operate quietly and eco-friendly, ideal for extended operation in scenic areas and resorts.
- Maintenance-free battery design reduces long-term operational costs and enhances visitor experiences.
🚐 RV and Outdoor Equipment
- Provides reliable power for RVs, electric boats, and camping equipment.
- Enables extended travel and outdoor activities, enhancing freedom and safety.
🤖 Industrial and Automation Equipment
- Widely applicable to AGVs, factory automated transport systems, and robots.
- Ensures prolonged continuous operation, helping businesses build efficient smart factories.
